Student Dissecting Microscopes

Student Dissecting Microscopes Specification

View Head
360 rotatable monocular head

Features
Compact, durable metal body, dust proof, easy to carry

Focus System
Rack and pinion with smooth motion

Spare Parts
Eyepiece pairs, stage clips, mirror

Theory
Upright, single body design for student use

Drawtube
Monocular, fixed

Sensor
Not applicable (optical only)

Resolution
Optical, based on eyepiece and objective pairing

Interface
Manual observation

Focal Distance
50 mm to 75 mm (approximately)

Magnification
10x and 20x standard

Dimensions
Approx. 180 mm (H) x 120 mm (W) x 110 mm (D)

Focus Range
Up to 20 mm

Eyepieces
10x paired wide-field lens

Eyepiece Tube
Single, straight tube

Illumination
Plano-concave mirror, natural/ambient light

Coarse Adjustment Range
Adjustable, 15 mm to 20 mm

Fine Adjustment Range
Not available (coarse only)

Working Stage
Glass stage plate, 75 mm diameter with fixed clips

Image Format
Visual observation

Interpupillary Distance
Fixed, suitable for most users

Objective Achromatic
2x objective (paired lens system)

Light Source
Mirror illumination, no built-in lamp

Base Material
Sturdy cast iron base for stability

Packing
Delivered with protective styrofoam and box

Stage Movement
Manual movement in X-Y direction

Finish
Corrosion-resistant enamel coating

Weight
Approx. 1.1 kg

Color
Standard white/grey finish

Usage
Ideal for school biology and basic laboratory dissections

About Student Dissecting Microscopes

STUDENT DISSECTING MICROSCOPE is a high resolution examining instrument that is commonly used in educational institutes and laboratories to get a magnified view of test samples that are not visible with the naked eye. Also known as a stereo microscope, this laboratory grade optical tool is capable of providing a three dimensional image for better visibility. The wide zooming ratio and high numerical aperture of the offered device ensure high imaging quality. The eyepiece can be easily adjusted as per the observers convenience. STUDENT DISSECTING MICROSCOPE availed by our company can be delivered to our clients as per the order placed by them at a reasonable price.

Brass parts complete with 2 eyepieces 10x and 20x. Packed in Thermocol box and Wooden Box.

Stability and Durability

This dissecting microscope features a robust cast iron base, providing excellent stability during use. The corrosion-resistant enamel coating ensures the microscope withstands regular wear in busy educational environments. Its dust-proof and compact design enhances longevity, making it suitable for frequent handling by students in classrooms and laboratories.

Optical Performance and Usability

Equipped with a paired wide-field 10x eyepiece and a 2x achromatic objective, the microscope delivers clear optical resolution suitable for biological specimen observation. The manual X-Y stage movement and rack-and-pinion coarse focus mechanism enable precise specimen positioning, while the 360 rotatable monocular head ensures comfortable viewing angles for users.

Easy Transport and Reliable Packaging

Weighing approximately 1.1 kg and featuring a compact design, the microscope is easy to carry between classrooms and labs. It is delivered with protective styrofoam and a sturdy box that prevents damage during transit or storage. The simple upright, single tube construction makes it easy for students to set up and use.

FAQ's of Student Dissecting Microscopes:

Q: How does the Student Dissecting Microscope achieve specimen stability during observation?

A: The microscope is designed with a sturdy cast iron base, which provides reliable stability and prevents movement during specimen examination. This ensures consistent focus and safety for users, especially in school environments.

Q: What is the process for adjusting focus on this dissecting microscope?

A: The microscope uses a rack-and-pinion coarse adjustment system, allowing smooth and precise movement of the stage within a range of 15 to 20 mm. Fine adjustment is not available, making it ideal for student-level explorations requiring basic but effective specimen focusing.

Q: When is this microscope most beneficial for educational use?

A: This model is particularly useful during biology classes, practical lab sessions, and basic dissections in schools. Its upright, monocular design and ease of manual operation make it optimally suited for introductory scientific training and hands-on learning.

Q: Where can this microscope be transported or used effectively?

A: Due to its compact and lightweight structure, the microscope can be conveniently used in classrooms, laboratory benches, and mobile science kits. Its protective packaging supports safe movement between locations, while the durable enamel finish resists environmental wear.

Q: What kind of illumination does the microscope utilize for specimen viewing?

A: The microscope employs a plano-concave mirror, harnessing natural or ambient light to illuminate slides. There is no built-in lamp, so its usage does not depend on electrical outlets, ensuring versatility in different teaching environments.

Q: How is magnification achieved, and what options are available on this microscope?

A: Magnification is provided via a 10x paired wide-field eyepiece and a 2x achromatic objective lens, giving users standard options of 10x and 20x magnification. The optical clarity depends on the combination of eyepiece and objective used.
