Vernier And Traveling Microscope

Vernier And Traveling Microscope
Vernier And Traveling Microscope

Vernier And Traveling Microscope Specification

  • Features
  • High stability heavy cast base, ground tracks for smooth carriage movement, precise vernier scale for accurate measurement, mechanical coarse and fine adjustment, robust construction, specimen clamping screws.
  • Focus System
  • Manual coarse and fine adjustment knobs.
  • View Head
  • Monocular, adjustable for focus.
  • Spare Parts
  • Eyepieces, vernier scale, screws, clamps, replacement lenses, knobs.
  • Theory
  • Used to measure small distances with high precision, combining the principle of vernier scale and micrometer accuracy for scientific and laboratory measurements.
  • Drawtube
  • Precision ground metal tubes; able to extend for fine focusing adjustments.
  • Sensor
  • Not applicable; manual mechanical measurement device.
  • Resolution
  • Typically 0.01 mm or 0.001 cm (10 micron or 1 micron accuracy depending on model).
  • Interface
  • Manual; readings are directly observed from scale and vernier.
  • Frame Rate
  • Not applicable; mechanical device.
  • Focal Distance
  • About 50 mm 60 mm depending on adjustment.
  • Magnification
  • Usually 10x to 15x optical magnification via eyepiece lens.
  • Dimensions
  • Approx. 400 mm x 160 mm x 250 mm (L x W x H).
  • Focus Range
  • Adjustable via fine focus knobs; vertical stage travel up to 15 cm.
  • Eyepieces
  • Wide field; standard supplied 10x magnifier optical glass lens.
  • Eyepiece Tube
  • Single monocular tube; metal construction with knurled focusing ring.
  • Illumination
  • Natural or external illumination; no built-in light source.
  • Coarse Adjustment Range
  • Carriage mounted on precision ground horizontal track; up to 15 cm traverse.
  • Fine Adjustment Range
  • Vernier scale allows increments as small as 0.01 mm.
  • Working Stage
  • Heavy metal stage with scale and clamping screws for specimen holding.
  • Still Image Capture Resolution
  • Not applicable; no electronic image capture.
  • Video Capture Resolution
  • Not applicable; no electronic video output.
  • Image Format
  • Visual only; direct optical observation.
  • Interpupillary Distance
  • Not applicable; single monocular eyepiece.
  • Objective Achromatic
  • Achromatic single lens, designed to reduce chromatic aberrations.
  • Condenser
  • Not applicable; illumination dependent on external source.
  • Light Source
  • External (e.g., desk lamp); no built-in illumination.
  • Material
  • Heavy cast iron base with brass and stainless steel fittings for durability.
  • Usage
  • Suitable for schools, colleges, research labs for scientific measurement of small objects, calibration, and precision engineering.
  • Safety
  • No electrical components; safe for educational and laboratory use.
  • Carriage Movement
  • Smooth movement along X and Y directions; micrometer head for fine adjustment.
  • Stage Scale
  • Clear metric graduation, least count typically 0.01 mm.
  • Inspection Method
  • Direct optical observation with manual fine and coarse movement controls.
  • Mounting
  • Non-slip rubber feet for stability.
  • Travelling Range
  • Horizontal: up to 20 cm; Vertical: up to 15 cm.
  • Weight
  • Approx. 6 kg 8 kg (depending on model and accessories).
  • Base
  • Stable cast iron base with anti-vibration rubber pads.
  • Operating Temperature
  • 10C 40C (ambient laboratory environments).
  • Vernier Scale Material
  • High-grade stainless steel with anti-rust finish.
  • Adjustment Knobs
  • Knurled metal knobs for precise adjustment and ease of use.


Vernier And Traveling Microscope Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Supply Ability
  • 10 Pieces Per Day
  • Delivery Time
  • 1 Week


About Vernier And Traveling Microscope

BTM401Vernier Microscope: (Traveling Microscope) with 18 cms. and 15cms. Stainless steel scales. Vernier reading to 0.01 mm, provided with achromatic objective and 10x Ramsden eye piece with fine cross line hair. Complete in nicely polished case.


Robust Construction for Long-lasting Accuracy

The microscope features a heavy cast iron base with non-slip rubber feet to minimize vibrations and ensure measurement stability. All critical fittings are made from brass and stainless steel, which resist corrosion and provide long-term durability, even in busy laboratory environments. Knurled adjustment knobs ensure smooth, precise control without slipping during operation.


Precision Measurements Made Simple

With its fine vernier scale, ground metal tubes, and achromatic optics, the instrument measures small distances as accurately as 0.01 mm. The metric stage scale and micrometer head facilitate reliable positioning along X and Y directions. This makes the device perfect for detailed calibration tasks, educational demonstrations, and precision engineering measurements.


Safe and Versatile for Educational Use

No electrical components are present, making the microscope safe for various educational settings. The device operates in ambient laboratory conditions (10C 40C), relying on natural or external illumination. Its mechanical design encourages hands-on learning and manual skill development, while spares and accessories ensure continued usability.

FAQs of Vernier And Traveling Microscope:


Q: How is the Vernier and Traveling Microscope operated?

A: The microscope is fully manual, with mechanical knobs for both coarse and fine adjustments. Measurements are directly read through the optical eyepiece and vernier scale, making data collection straightforward and requiring no electronic interface.

Q: What are the main benefits of using this microscope?

A: It offers highly accurate measurement of small distancesdown to 0.01 mmthanks to its robust design, precision machined components, and optical magnification. Its stable base and anti-vibration features maximize accuracy, supporting reliable results in research and education.

Q: Where is this microscope typically used?

A: It is commonly employed in schools, colleges, and research laboratories. Its application spans calibration, scientific measurement of minute objects, and precision engineering work that requires meticulous attention to detail.

Q: What process does it use to achieve precise measurement?

A: The device combines the principles of the vernier scale and micrometer accuracy. The carriage moves smoothly along precision-ground tracks, and the user visually observes the measurement through the microscopes monocular lens, adjusting fine and coarse controls as needed.

Q: How is safety ensured during operation?

A: With no electrical or electronic components, the microscope is inherently safe. Its sturdy cast iron base with rubber feet discourages slippage and vibration, while mechanical construction avoids common electrical hazards in lab environments.

Q: What are the usage conditions for optimal performance?

A: For best results, operate the microscope in laboratory environments with ambient temperatures between 10C and 40C. Use natural or external sources of illumination, and ensure the specimen is securely clamped on the working stage for stable measurement.

Vernier And Traveling Microscope

Price 4000 INR/ Piece

  • Minimum Order Quantity
  • 1 Piece
  • Supply Ability
  • 10 Pieces Per Day
  • Delivery Time
  • 1 Week
