Trinocular Stereo Zoom Microscope

Trinocular Stereo Zoom Microscope Specification

View Head
Trinocular

Features
Continuous zoom, dual illumination, trinocular port for photomicrography, ergonomic design

Spare Parts
Eyepieces, objective lenses, fuse, stage plate

Focus System
Rack and pinion, tension adjustable

Theory
Trinocular Stereo Zoom Microscope designed for high-definition observation and documentation of specimens with simultaneous binocular observation and camera usage.

Drawtube
Trinocular head, inclined 45, rotatable 360

Sensor
Compatible with digital imaging systems (sensor/camera not included)

Resolution
Up to 1080p (with appropriate camera attachment)

Interface
C-mount for camera attachment

Frame Rate
Dependent on camera; typically 30fps or higher with digital cameras

Focal Distance
100mm-110mm

Magnification
Zoom 7x to 45x (with standard 10x eyepieces), expandable with auxiliary objectives and optional eyepieces

Dimensions
Approx. 290mm 265mm 360mm

Focus Range
55mm

Eyepieces
Widefield 10x/20mm, focusable, pair with eye guards included

Eyepiece Tube
Diopter adjustment on both tubes

Illumination
Built-in LED Incident (top) and Transmitted (bottom) illuminators, intensity adjustable

Coarse Adjustment Range
55mm

Fine Adjustment Range
Not applicable (only coarse focusing in stereo microscopes)

Working Stage
Flat black/white reversible stage plate; glass stage plate for transmitted light use

Still Image Capture Resolution
Dependent on attached camera module

Video Capture Resolution
Dependent on camera module attached

Image Format
Dependent on attached camera (JPEG, BMP, TIFF, etc.)

Interpupillary Distance
Adjustable, 55mm-75mm

Objective Achromatic
0.7x - 4.5x zoom objective lens system

Condenser
Not required for stereo microscope

Light Source
LED, 3W (top and bottom)

About Trinocular Stereo Zoom Microscope

ZOOM RATIO 1:4 -Long working distance :82 mm with Dual Light stablest and with ball bearing slide & large size knobs for smooth focusing. Dual illumination Built inillumination both for incident light (12V-20W Halogen) and Transmitted light(12V-10W) on dual light stand. Binocularzoom Pod 1:4, Inclined at 45 deg., Inter papillary distance 54mm -74mm. with fixed or focus able movement. Stage Plate: One of 5mm Thick Glass, another one of molded ABS-One side black other side white, easily replacable, with 2 stageclips.

Total Magnification Range 10x to 160xwith Optional

Eyepieces Paired	Objectives
	1x-4x Standard Zoom Objective	2x-8x with Aux.2x Objective
With 10xWF (FN 20 )	10x to 40x	20x to 80x
With 15xWF (FN 15 )	15x to 60x	30x to 120x
With 20xWF (FN 13)	20x to 80x	40x to 160x

Auxiliary Objective

Optional:

Eyepieces : WF 15x (FN16) WF 20x (FN12)

Auxiliary objectives : 0.5x, 1.5x or 2x

Same as BTM 420 But provided with Trinocular head inclined binocular observation and straight tube for photomicrography

Stable and Durable Construction

Designed with a sturdy metal alloy body and robust, anti-vibration base, this microscope stands out for its stability and durability. The anti-rust powder coating ensures longevity even in rigorous lab environments, while the white and black accents give it a modern look suitable for professional settings.

Professional Imaging and Documentation

The trinocular head allows simultaneous specimen observation and camera integration via a standard C-mount, making this microscope perfect for high-resolution imaging and documentation. Compatible with digital systems, it enables live viewing, captured stills, or video at up to 1080p resolution, dependent on the attached camera module.

Versatile Magnification and Ergonomics

Offering a magnification range from 7x to 45x with widefield focusable eyepieces, the microscope ensures comfortable viewing through adjustable interpupillary distance, diopter settings, and ergonomic inclined design. Expandable optics and dual LED illumination provide adaptability for various specimen types and observation techniques.

FAQ's of Trinocular Stereo Zoom Microscope:

Q: How do I attach a digital camera to the trinocular stereo zoom microscope?

A: You can mount a compatible digital camera using the C-mount interface on the trinocular port. Please make sure your camera or sensor has the correct C-mount adapter for secure attachment.

Q: What power source is needed to operate the microscope?

A: The microscope operates on AC 90-240V, 50/60Hz, making it compatible with standard electrical outlets globally. No batteries are required for illumination or operation.

Q: When should I use the incident versus transmitted LED illumination?

A: Incident (top) illumination is best for examining opaque specimens, while transmitted (bottom) illumination is ideal for viewing transparent samples. Both light sources offer adjustable intensity to optimize image quality for your application.

Q: Where can this microscope be used effectively?

A: This trinocular microscope is suitable for laboratory, industrial, classroom, or research environments. Its robust construction and anti-vibration base make it ideal for precise observation in professional settings.

Q: What steps should I take to maintain the microscope?

A: To ensure longevity, keep the microscope covered with the included dust cover when not in use, avoid exposure to temperatures outside the 10C to 40C range, and clean the lenses with proper optical lens paper. Spare parts like eyepieces, objective lenses, and stage plates are replaceable.

Q: How do I adjust focus and magnification during observation?

A: Coarse focus is achieved using the rack and pinion system with tension adjustment. Magnification is continuously variable from 7x to 45x via the zoom control. For extended ranges, auxiliary objectives or optional eyepieces can be fitted.

Q: What are the benefits of the trinocular port and ergonomic design?

A: The trinocular port allows simultaneous observation and digital imaging, facilitating efficient documentation and presentations. The ergonomic design reduces user fatigue, with adjustable eyepiece positions and a 45 inclined head for comfortable long-term use.
