Fume Hood

Fume Hood Specification

Vaccum Range
Up to 100 mm Hg

Pressure Range
-10 Pa to 80 Pa

Hole Size
Customizable

Noise Level
< 55 dB

Energy Consumption
Low

Ventilation
Rear-sided, Ducted

Features
Chemical Resistant, Flame Retardant

Efficiency (%)
99.95%

Filtration Property
Multi-Stage

Dust
Particle-Free

Connectivity Type
Standalone

Humidity %
60%

Material
Epoxy Coated Steel Sheet

Color
White & Blue

Frequency
50 Hz

Maintenance Type
Manual Cleaning

Output
Filtered Air

Application
Industrial & Research Laboratory

Dust %
0.1%

Flow Rate
1100 m/hr

Filters
HEPA & Activated Carbon

Installation Type
Floor Mounted

Control System
Digital Display Control

Automatic Grade
Semi-Automatic

Capacity
Standard Lab Capacity

Power
230 W

Voltage
220 V

Dimension (L*W*H)
1200 x 800 x 2200 mm

Weight
120 kg

Fume Hood Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Day

Delivery Time
1 Week

About Fume Hood

BTI180 FUME HOOD

Fabricated out of thick wooden board. It is designed so as to throw-out all toxic/harmful vapors & fumes thus protecting costly instruments and the persons working in the lab. Outer is finished with sunmica and inner epoxy painted. Working table top is acid/alkali resistant and a small wash basin with connections provided for inlet and outlet of water. The front door moves vertically up and down with concealed counter balanced weights. The unit is fitted with fluorescent light and a gas cock for gas/air supply. The front facing panel is fitted with 15/5 Amp socket with switches for exhaust system and fluorescent light. To work on 220/230 volts A.C. supply.

Size Specifications :-

Working chamber size:

3x2x2

4x2x2

5x2x2

6x2x2

Optional Accessories :

High CFM exhausts System (for duct exceeding 10 feet in length)
S.S. Lining on work bench
PVC Fume Duct (per ft.)

Industries where this product is used :

Institutes, Medical Colleges, Industries, Pharmacy colleges and Industry, Laboratories, Pharmaceutical Industry, Hospitals

Designed for Safety and Compliance

With airflow monitoring, sash height alarms, and compliance to EN 14175 and CE standards, the FH-Lab1200 prioritizes operator safety in hazardous laboratory environments. Real-time digital controls ensure correct operating conditions, while the option for flame retardant coatings and chemical-resistant surfaces further enhances laboratory security.

Efficient Filtration and Ventilation

Outfitted with both HEPA and activated carbon filters, the multi-stage filtration system maintains a dust-free, particle-free workspace. The centrifugal fan and rear-sided ducted ventilation effectively remove harmful vapors, while maintaining a comfortable noise level and optimal air velocity during operation.

User-Friendly Features

The vertical sliding sash, easy-to-clean coat finish, underhood chemical storage, adjustable baffles, and integrated twin 230V sockets contribute to a highly functional and ergonomic laboratory setup. Maintenance is simplified by accessible service fittings and removable panels.

FAQs of Fume Hood:

Q: How does the FH-Lab1200 fume hood ensure user safety during hazardous chemical experiments?

A: The FH-Lab1200 integrates digital real-time airflow monitoring, automatic alarms for airflow failure and over-height sash opening, EN 14175 and CE compliance, and optional fire suppression systems. These features collectively protect users from hazardous chemical exposure and operational accidents.

Q: What is the process for adjusting air velocity and filtration in this fume hood?

A: Air velocity is controlled via the sash height, optimally set at 0.5 m/s during use. Filtration is managed through the hoods multi-stage system, utilizing both HEPA and activated carbon filters, along with removable, adjustable baffles and a centrifugal exhaust fan to regulate and purify air flow.

Q: When is maintenance required for the FH-Lab1200, and how is it performed?

A: Routine manual cleaning of surfaces and periodic inspection of the filters and exhaust system are recommended to maintain efficiency. Removable baffles and access panels facilitate easy filter replacement and cleaning, ensuring continued safe operation and compliance with laboratory standards.

Q: Where can the FH-Lab1200 fume hood be installed, and what are its space requirements?

A: The unit is floor-mounted and suitable for industrial or research laboratory settings in India. Its dimensions (1200 x 800 x 2200 mm) require adequate floor space and rear-sided ducting for exhaust. Customizable hole sizes accommodate various installation configurations.

Q: What is the benefit of using epoxy resin and tempered glass in the construction of this fume hood?

A: Epoxy resin provides a chemical-resistant, flame retardant, and temperature-resistant (up to 180C) worktop, while tempered glass ensures increased durability and safety for the window, offering clear visibility and protection against breakage during laboratory operations.

Q: How does the fume hood support research activities with its service fittings and output features?

A: With integrated gas and water valves, twin 230V electrical outlets, digital control system, and filtered air output, the FH-Lab1200 facilitates robust research activities, supporting a wide variety of laboratory instruments and processes while ensuring a clean and safe working environment.
